Commercial & Industrial Solar System Solutions
GoodWe provides commercial and industrial energy solutions for EPCs, developers, and owner-operators to utilize the roof resources. With unrivalled technical expertise and optimized design, GoodWe can comprehensively drive new revenue streams and project value for our users with high-current PV module compatibility.
Up to 150% DC input oversizing
Up to 115% AC output overloading
Up to 99% max. efficiency
Up to 12 MPP trackers
Full load operation at 50 °C
Power line communication
String level current monitoring
Free lifetime access to SEMS portal
Fast localized service
Commercial On-Grid Rooftop System
Commercial On-Gird PV Plant
Commercial Storage System
SDT G2 Series
The GoodWe SDT Series is one of the best options available on the residential & commercial segments thanks to its technical strengths that make it one of the most efficient in the market. For enhanced safety, this inverter is able to incorporate AFCI. Its high efficiency (98.3%) and its enhanced oversizing & overloading capabilities represent an outstanding improvement in the industry. Moreover, its plug-in AC connector make operation & maintenance easier.
Three phase ∣ Up to 12 MPPTs
The new HT 1100 Vdc Series (73-136 kW) is GoodWe's new string inverter for C&I and small utility projects. The HT series offers up to 12 MPPTs, and is compatible with bifacial modules, with a higher threshold of DC current (Max. 15A per string). It includes PLC communication and internal humidity detection. The HT series seamlessly incorporates different sets of technical strengths designed to achieve higher savings in the installation, enhance productivity and diversify available monitoring options, taking safety to the maximum possible level in accordance with the strictest industry standards. This inverter comes with an optional AC switch for reduced overall costs and reduced installation time. Configuration can be easily done via Bluetooth, and diagnosis and firmware upgrading can be operated remotely. This outstanding set of features was conceived to ensure the lowest levelized cost of electricity (LCOE).
Developed as an efficient response to South American market needs for low-voltage inverters, GoodWe’s LVMT series inverter is suitable for medium and large scale commercial rooftops or ground-mounted solar PV systems where maximum versatility and profitability are important. With its compact design and power boost function, GoodWe’s LVMT series can provide extremely high efficiency of 98.8%, thus offering a faster return on investment.
GoodWe's LVSMT series three-phase inverter is designed with low voltage power input, specifically tailored to small commercial PV applications. Developed as an efficient response to South American market needs for low-voltage inverters above 10 kW, the GoodWe LVSMT series is applicable to the different grid voltage ranges in the region, which mainly cover 208 V, 220 V and 240 V. With the GoodWe LVSMT series inverter, the system configuration can be simplified by avoiding the installation of an expensive transformer which adversely affects the system’s conversion efficiency.
SDT G2 Series
The GoodWe 17-25 kW SDT G2 series inverter is especially designed for three-phase residential and small commercial projects. With its compact design, the SDT G2 inverter is 45% smaller than the first generation. The inverter is also light and easy to install. The maximum efficiency of this inverter is as high as 98.4%. With an advanced ventilation system, the inverter is able to dissipate heat efficiently. In addition, it can be customised with an integrated LCD screen.
225/250 kW ∣ Three phase ∣ 6/12 MPPTs
The new HT1500V Series (225/250kW) is GoodWe’s top inverter with an extensive list of features designed to reduce system and O&M costs. It is a perfect choice for the utilization of utility-scale centralized PV plants to maximize the return of investment.The HT1500V Series boasts options of 6 MPPTs and 12 MPPTs, power line communication 2.0, and is compatible with bifacial 182mm/210mm modules. It features string level monitoring and incorporated I-V curve diagnosis for intelligent detection of voltage and current issues. The series is also equipped with optional PID recovery function and can realize 24-hour monitoring. For GW225KN-HT & GW250KN-HT, the unique mechanism of smart string protection switch will minimalize the energy generation loss when a short circuit or reverse connection occurs. The configuration of the HT1500V can be easily done via Bluetooth, while firmware diagnosis and upgrading can be operated remotely. These outstanding sets of features were conceived to ensure the lowest levelized cost of energy (LCOE) and a utility that runs efficiently.
Hybrid inverter (HV)
GoodWe ETC Series is a three-phase battery storage inverter with wide battery voltage range from 200 to 865V. It follows a simple, Plug & Play modularized design consisting of five main modules (MPPT, DC/DC, DC/AC, STS & EMS modules), which allows more flexible and easier installation.
It can switch to backup mode in less than 10 ms ensuring uninterruptible power supply for critical loads. It offers 110% continuous AC overloading on backup for maximum power output and emergency shutdown function for system safety.
The active, reactive power and power factor of this inverters is fully adjustable, which makes it suitable for micro-grids and ensures grid stability for the whole system. Whether to increase self-consumption, to realize peak-shaving, or for on-/off-grid use, the ETC series is the perfect energy storage solution for commercial and industrial applications.
Smart Energy Management System
GoodWe Smart Energy Management System (SEMS) is a cost-free monitoring platform which offers reliable operation of photovoltaic plants with maximum yield.SEMS allows operators to simultaneously monitor a diverse range of photovoltaic power plants in different locations in real time and control the installations. Extensive data processing, customized charts, and alarm and maintenance functions ensure that operators, operations managers and asset managers can comfortably and efficiently manage the systems, ensuring maximum yields.
SEMS includes a range of functions and features to ensure reliable operation and to deliver precise information to operators at the press of a button. It is accessible by multiple accounts with different levels of access for owners, installers and EPC companies.
4G KIT-EC / 4G KIT-AU
GoodWe 4G Module is easy to install with Plug-Play design and can support several operators worldwide, offering customers convenience and reliability especially in remote areas without access to Wi-Fi.
Smart Energy Controller
SEC1000 (On Gird) / SEC1000S (Storage)
The SEC is a smart energy controller entirely developed by GoodWe. When combined with a GoodWe solar inverter, it is able to achieve real-time data collection and analysis. Furthermore, the SEC can automatically adjust active power output, power factor and other parameters of a solar power plant. It can even limit AC output to the grid, which further distributes and allocates system resources more effectively. The SEC is composed of GoodWe's three-phase meter and control board. It can be connected with SEMS to control and manage the performance of inverters in each string. Small box, mighty functions!
Solar Communication Box 2000
SCB2000 With Optical / SCB2000 Without Optical
The SCB2000 (Solar Communication Box) integrates the following component sections: a PLC communication board, a data collecting Ezlogger Pro board, a GPRS module (optional), a fiber ring network switch (optional) and a three-phase/single-phase switch.
Solar Communication Box 3000
The SCB3000 (Solar Communication Box) integrates PLC 2.0 to enhance anti-interference ability, transmission rate & communication distance, and can be adapted to I-V curve diagnosis function, which makes it a perfect match for smart inverters.
The EzLogger Pro is a self-developed monitoring device by GoodWe. In combination with a GoodWe solar inverter, it can easily read and record all key plant data and constantly transmit the data to the GoodWe portal via the internet.
Wi-Fi BOX / Wi-Fi KIT
· Data encrypted to ensure data security.
· Supports breakpoint retransmission - automatic disconnection of broken links, reconnection and subsequent transmission to prevent data loss.
· Remote upgrade - inverter program update without going on site.
· Pre-assembled, tested and shipped - no on-site installation required, stable performance.
5pin (LAN BOX) / USB (LAN KIT)
· High-speed and realible transmission via Ethernet Cable.
· Support encyption to ensure data security.
· Support the continuation of breakpoint.Automatically save when commucation disconnection occurs, and resconnect subsequent transmissiom to ensure that data is not lost.
· Support remote upgrade.Inverter upgrade can be achieved without having be on site in person.
