6 MPPTs
98.6%
The SMT G2 Series string inverters (35–80kW) are designed for C&I applications, delivering high energy yields and exceptional power density. The 35–50kW models are tailored for low-voltage (127/220Vac) installations. Across the range, support for high-power PV modules is ensured through multiple MPPTs and up to 21A input current per string, delivering consistently optimized performance. The SMT G2 Series comes in two designs: a compact, ultra-low-noise version for the 35/37.5/60kW models, and a reinforced, high-power-density version for the 50/75/80kW models. For reliability, the series includes Type II surge protection on both DC and AC sides, with optional AFCI for enhanced protection.
Remote data monitoring
Up to 200% DC input oversizing
Lightweight 42 kg design with <50 dB full-load noise
IP66 protection for outdoor installation safety
6 MPPTs
98.6%
Flexible & Adaptable Solutions
The SMT G2 series offers two distinct ranges to meet diverse project requirements. The 35–60 kW models deliver cost-effective flexibility with a lightweight, low-noise design, making installation simple even in compact or noise-sensitive environments. The 50–80 kW models emphasize high yields and power density, with a 6-MPPT design and support for 182/210 mm high-current modules. From small rooftops to ground-mounted plants, SMT G2 provides the right balance of value and performance.
Compatible with 182/210mm modules
Lightweight 42 kg design with <50 dB full-load noise
Consistent Efficiency & Reliable Protection
The SMT G2 Series supports up to 200% DC oversizing and achieves a maximum efficiency of 98.8%, ensuring optimal energy generation under varying conditions. With Type II surge protection, IP66-rated durability, and optional functions such as AFCI, PID recovery, and night SVG, it offers robust protection and dependable performance for long-term operation.
200%
Up to 200% DC input oversizing
98.8%
Max. efficiency
IP66
IP66 protection for outdoor installation safety
OVERVIEW
Model
GW35K-SMT-L-G20
Max. Input Voltage (V):
900
Max. Input Current per MPPT (A):
42
Number of MPP trackers/Number of Strings per MPPT:
4/2
Max. Efficiency :
98.4%
Nominal Output Voltage (V) :
127 / 220, 3L / N / PE or 3L / PE
Model
GW37.5K-SMT-L-G20
Max. Input Voltage (V):
900
Max. Input Current per MPPT (A):
42
Number of MPP trackers/Number of Strings per MPPT:
4/2
Max. Efficiency :
98.4%
Nominal Output Voltage (V) :
127 / 220, 3L / N / PE or 3L / PE
Model
GW60K-SMT-G20
Max. Input Voltage (V):
1100
Max. Input Current per MPPT (A):
42
Number of MPP trackers/Number of Strings per MPPT:
4/2
Max. Efficiency :
98.8%
Nominal Output Voltage (V) :
220 / 380, 230 / 400, 3L / N / PE or 3L / PE
Model
GW50K-SMT-L-G10
Max. Input Voltage (V):
900
Max. Input Current per MPPT (A):
42
Number of MPP trackers/Number of Strings per MPPT:
6/2
Max. Efficiency :
98.6%
Nominal Output Voltage (V) :
127 / 220, 3L / N / PE or 3L / PE
Model
GW75K-SMT
Max. Input Voltage (V):
1100
Max. Input Current per MPPT (A):
42
Number of MPP trackers/Number of Strings per MPPT:
6/2
Max. Efficiency :
98.6%
Nominal Output Voltage (V) :
220 / 380, 3L / N / PE or 3L / PE
Model
GW80K-SMT
Max. Input Voltage (V):
1100
Max. Input Current per MPPT (A):
42
Number of MPP trackers/Number of Strings per MPPT:
6/2
Max. Efficiency :
98.6%
Nominal Output Voltage (V) :
220/380, 230/400, 3L/ N/PE or 3L/PE
