MIS G2 Series (4-in-1）
1600-2250W | Single Phase | 4MPPTs | Micro Inverter
DOWNLOAD PDF >>
＜20dB
50°C Full Power
IP67
The MIS G2 series is a high-performance microinverter solution engineered for maximum energy harvest and long-term reliability. Featuring a compact architecture and advanced Wi-Fi Mesh networking, it eliminates the need for external gateways while simplifying installation. With an industry-leading 15-year warranty and a 50°C full-power threshold, the MIS G2 is the ideal choice for secure and scalable solar investments in both residential and small commercial applications.
12V ultra-low startup voltage
30% lighter design for solo installation
Full power output up to 50°C
Wi-Fi Mesh connecting up to 25 units
<20dB whisper-quiet operation
＜20dB
50°C Full Power
IP67
Maximized Energy Harvest
Designed to outperform in real-world conditions, the MIS G2 maintains 100% power output even as rooftop temperatures reach 50°C. By pairing a 20A input current with an ultra-low 12V startup voltage, the system captures maximum energy from modern high-power modules from early morning until late evening.
12V ultra-low startup voltage
Max. 20A DC input current
Full power output up to 50°C
Reliability Without Compromise
Featuring IP67-rated sealing and C4M-certified anti-corrosion technology, the MIS G2 is built to withstand everything from heavy rain and dust storms to the high-salinity air of coastal regions. This industrial-grade protection ensures a long, maintenance-free service life in the harshest environments.
IP67 & C4M-certified protection
<20dB whisper-quiet operation
15-year standard warranty
Smart Control & Monitoring
Advanced Wi-Fi Mesh technology eliminates the need for traditional communication hardware, reducing system cost and complexity. By enabling seamless interconnection for up to 25 units, the MIS G2 delivers stable and scalable connectivity, making energy management smarter and more intuitive for any project size.
25
Wi-Fi mesh connection for up to 25 units
Network-free shutdown capability
Second-level monitoring via SEMS + app
OVERVIEW
Model
GW2.5K-MIS-G20
Max. Input Voltage (V)
60
Max. Input Current per MPPT (A)
20
Number of MPP Trackers/Number of Strings per MPPT
4/1
Weight (kg)
≤5.1
Ingress Protection Rating
IP67
Model
GW2.25K-MIS-G20
Max. Input Voltage (V)
60
Max. Input Current per MPPT (A)
20
Number of MPP Trackers/Number of Strings per MPPT
4/1
Weight (kg)
≤5.1
Ingress Protection Rating
IP67
Model
GW2K-MIS-G20
Max. Input Voltage (V)
60
Max. Input Current per MPPT (A)
20
Number of MPP Trackers/Number of Strings per MPPT
4/1
Weight (kg)
≤5.1
Ingress Protection Rating
IP67
Model
GW1.875K-MIS-G20
Max. Input Voltage (V)
60
Max. Input Current per MPPT (A)
20
Number of MPP Trackers/Number of Strings per MPPT
4/1
Weight (kg)
≤5.1
Ingress Protection Rating
IP67
Model
GW1.8K-MIS-G20
Max. Input Voltage (V)
60
Max. Input Current per MPPT (A)
20
Number of MPP Trackers/Number of Strings per MPPT
4/1
Weight (kg)
≤5.1
Ingress Protection Rating
IP67
Model
GW1.6K-MIS-G20
Max. Input Voltage (V)
60
Max. Input Current per MPPT (A)
20
Number of MPP Trackers/Number of Strings per MPPT
4/1
Weight (kg)
≤5.1
Ingress Protection Rating
IP67
